Cincoze® P1000 Series Panel PC
Product Series: P1000
The Cincoze P1000 Series is a modular industrial panel PC platform designed for entry-level performance computing in rugged environments. Built around the Intel® Alder Lake-N processors, the P1000 Series offers fanless operation, wide temperature tolerance, and a versatile I/O architecture. With support for Cincoze’s Convertible Display System (CDS) technology, users can pair the P1000 embedded computer with a variety of display modules ranging from 8.4" to 24", available in capacitive, resistive, or non-touch options—including both standard and sunlight-readable brightness for indoor or outdoor deployment—ideal for applications in industrial automation, transportation, and machine vision.
- Intel® Core™ i3-N305, Processor N97, or Atom® x7425E CPUs
- Fanless, cableless, and vibration-resistant in −40°C – 70°C
- 8.4" – 24" sunlight-readable with capacitive or resistive screen
- Add PoE or Ignition Sensing via CFM modules
- IP65-rated front panel, 9–48V DC input
- Complies with UL, cUL, CB, CE, FCC, MIL-STD-810G standards
- Supports panel, VESA, and wall mounting
Processor
Intel® Core™ i3-N305
Intel® Processor N97
Intel® Atom® x7425E
Operating System
Windows® 10/11 IoT
Ubuntu® Linux
Memory
(1) DDR5 SO-DIMM Socket, Up to 16GB
Storage
(1) M.2 Key B 3042/3052 Slot
(1) 2.5″ SATA SSD Bay
Display Options
8.4″ – 24″ TFT-LCD
Standard or sunlight-readable
Capacitive, resistive, or non-touch
Graphics Output
(1) DisplayPort
(1) VGA
USB Ports
(4) USB 3.2 Gen2 Type-A
LAN Ports
(2) 2.5 GbE LAN
Serial Ports
(4) COM (RS-232/422/485)
Expansion Slots
(1) M.2 Key E Type 2230
(1) M.2 Key B Type 3042/3052
Power Input
9–48V DC
Ignition control support
Operating Temperature
−40°C − 70°C
Certifications
CE
FCC
EN 61000-6-2/4
MIL-STD-810G
Mounting Options
Panel mount
VESA mount
Wall mount
Dimensions
204.5 x 149 x 46.5 mm
(varies by display)
Weight
~1.1 kg (varies by display)
