NVIDIA® Jetson™ AGX Orin™ AI PC
Product Series: PE2100N
The ASUS IoT PE2100N is a rugged, fanless edge AI system powered by the NVIDIA® Jetson™ AGX Orin™ platform, delivering up to 275 TOPS of AI inference performance. Designed for demanding applications such as machine vision, autonomous vehicles, and intelligent video analytics, the PE2100N offers versatile I/O options, including (1) GbE, (1) 10GbE, and (4) PoE GbE ports. Its robust design supports a wide operating temperature range of −25°C to 55°C and a wide power input range of 9 to 36 VDC, making it suitable for intense industrial environments.
- Equipped with the NVIDIA® Jetson™ AGX Orin™ platform, delivering up to 275 TOPS for high-performance AI inference tasks.
- Offers a range of I/O options, including (1) GbE, (1) 10GbE, and (4) PoE GbE ports, facilitating data transmission and power supply via Ethernet.
- Features three M.2 slots (M-Key, E-Key, B-Key) for SSDs, Wi-Fi/BT modules, and 4G/5G connectivity, allowing customization for various applications.
- Fanless operating temperature range of −25°C – 55°C and wide power input from 9 – 36 VDC, ensuring reliable performance in harsh environments.
- Ideal for machine vision, autonomous mobile robots (AMRs), automated optical inspection (AOI), and intelligent video analytics in industrial settings.
Processors
(1) NVIDIA® Jetson™ AGX Orin™ (32GB or 64GB)
Memory
Up to 64GB 256-bit LPDDR5
Storage
(1) eMMC 64GB
(1) M.2 M-Key 2280 for SSD
(1) Micro SD slot
Expansion Slots
(1) M.2 E-Key 2230 for Wi-Fi/BT
(1) M.2 B-Key 3042/3052 for 4G/5G
(1) Micro SIM slot
Ethernet Ports
(1) RJ-45 10/100/1000 Mbps
(1) RJ-45 10 Gbps
(4) PoE RJ-45 10/100/1000 Mbps (802.3af/at)
USB Ports
(1) USB 3.2 Gen2 Type-C
(2) USB 3.2 Gen1 Type-A
(1) USB 2.0 Type-C for OS Flash
Serial Ports
(1) RS-232 DB9
(1) RS-422 DB9
Power Input
9–36 VDC
Operating Temperature
−25°C − 55°C
Mounting Options
Wall Mount
DIN Rail
Dimensions
270 x 195 x 80 mm
Weight
4.2 kg
Certifications
CE
FCC
MIL-STD-810G
