ASUS NUC 16 Pro Mini PC
Product Series: AIOT-NUC-16-PRO
The ASUS NUC 16 Pro combines enterprise reliability with the latest Intel® Core™ Ultra processors to power intelligent edge deployments, AI inferencing, and business-critical workloads. With Intel vPro® Enterprise for robust manageability and security, this 6x4-inch mini-PC is engineered for always-on performance in commercial environments. The integrated Intel® AI Boost NPU enables efficient on-device AI acceleration, while support for DDR5 memory and Thunderbolt™ 4 ensures blazing-fast data throughput. A fanless chassis option and tool-free access make it a flexible, serviceable solution for embedded applications.
- AI-optimized with Intel® Core™ Ultra and built-in NPU
- Supports 24/7 operation in demanding environments
- Four 4K display outputs for immersive visual applications
- Compact and modular with VESA and desktop mounting options
- Preinstalled with Windows® 11 IoT or Ubuntu®
Storage? Sorted.
When calculating storage and performance needs for your project, it's important to know not only the available raw storage, but also the system’s usable storage. This figure accounts for how RAID configuration, disk type, formatting, and performance overhead affect real world capacity.
Management? Simplified.
Velasea's exclusive partnership with Canopy software enables every IRON LINK® appliance with the option of Remote Device Management and Monitoring capabilities, allowing for a unified overview of your entire fleet and significantly decreased downtime. Truck rolls? No, thank you!
Processors
Intel® Core™ Ultra 5 325
Intel® Core™ Ultra 7 356H
Intel® Core™ Ultra 7 356H (vPro)
Intel® Core™ Ultra 7 358H
Intel® Core™ Ultra 9 378H
Operating System
Windows® 11 IoT
Windows® 11 Pro
Ubuntu® Linux
Memory
(2) SO-DIMM, DDR5-6400 (Up to 128GB)
Storage
(1) M.2 2280 PCIe Gen4 NVMe SSD
(1) M.2 2280 PCIe Gen5 NVMe SSD
Supports up to 8TB per drive
Graphics
Intel® Arc™ Graphics
Intel® Graphics
Networking
(2) Intel® Ethernet Controller i226-V 2.5G
(1) Intel® Wi-Fi 7 BE201 (Gig+), Bluetooth 6.0
Power Supply
19VDC 6.32A 120W Power Adapter (U5/U7)
19.5VDC 7.7A 150W Power Adapter (U9)
Dimensions (WxDxH)
5.67” x 4.41” x 1.65”
(144mm x 117mm x 42mm)
Weight
1.6lb (730g)
Operating Temperature
0°C – 40°C (32°F – 104°F)
Ports/Slots
FRONT:
(1) USB 3.2 Gen 2×1, Type-C
(2) USB 3.2 Gen 2, Type-A
(1) Kensington Lock
REAR:
(2) Thunderbolt 4, Type-C w/ DP 2.1
(2) USB 3.2 Gen 2, Type-A
(2) HDMI 2.1 (TMDS Compatible)
(2) RJ45 LAN
(1) DC-in
Warranty
3-Year Depot
